Custom Spray Bottle Boxes & Spray Bottle Packaging
Spray bottles are one of the trickier items to box properly. The trigger or pump sticks out, the neck is wider than the body on most designs, and there is liquid inside that nobody wants leaking into the carton. Get the internal dimensions wrong and you either crush the actuator or the bottle rolls around all the way to the customer. We handle a lot of spray bottle packaging at ZEE Packaging, so here is what actually matters.
Measure The Pump, Not The Bottle
This is the mistake we correct most often. People send us the bottle height and forget the sprayer sitting on top.
- Measure with the trigger or pump fitted and locked down
- Add the shroud width, trigger heads are wider than the neck
- Account for the dip tube if it is packed separate
- Leave 2 to 3mm tolerance so the spray bottle box closes flat
- Note whether the cap ships on or off
Send us those numbers, or just mail a sample bottle over and we will size the spray bottle box here.
- Tuck end carton the everyday spray bottle box for retail
- Seal end carton glued ends, better tamper resistance for chemicals
- Auto lock bottom pops open one handed, good for heavier fills
- Corrugated mailer ecommerce spray bottle packaging going direct
- Multipack shipper for two, four and six units
- Window carton shows the liquid color, works for cleaning and beauty
Sizes We Print Often
Every spray bottle box is built around your bottle, but these come up regular:
- 2.5" x 2.5" x 8" for 8oz pump bottles
- 3" x 3" x 9" for 16oz trigger spray bottle boxes
- 3.5" x 3.5" x 11" for 24oz and 32oz
- 2" x 2" x 6" for travel and mist bottles
- 7" x 4" x 10" for a two pack
- 10" x 7" x 11" for a six pack spray bottle packaging shipper
Board For A Liquid Filled Product
Weight is the deciding factor here. A full 32oz bottle is heavy and a thin base panel will give out.
- 20pt to 24pt cardstock for a single spray bottle box
- Corrugated E flute for shipping single units
- B flute for multipacks and heavier fills
- SBS C1S for printed retail spray bottle packaging
- Kraft board for eco and refill ranges
We do not recommend anything under 18pt once you pass 16oz. It looks fine empty and fails once filled.
Compliance On The Panel
Cleaning and chemical products carry more mandatory copy than most:
- GHS pictograms where the formula requires it
- Hazard and precautionary statements
- Ingredient list and net contents in fl oz and ml
- Directions for use and surface guidance
- Barcode with proper quiet zone
- Batch and lot code space, leave blank for inkjet
Our prepress team checks all of this against the dieline so nothing gets trimmed at the edge.
Finishing Options
- Matte or gloss lamination, matte hides handling marks better
- Soft touch for premium home and beauty spray bottle packaging
- Spot UV over the logo
- Foil stamping on gift and salon ranges
- Window patching with clear PET film
- Moisture resistant coating if the carton sits in a damp area
Greener Choices
- Recycled kraft spray bottle box with no film
- FSC certified board, certificate on request
- Soy based inks
- Uncoated finish that recycles curbside
- Right sized spray bottle packaging so you ship less air
How We Work
- 100 unit minimum on any spray bottle box design
- Free 3D mockup and flat proof
- Free dieline from our own designer
- 5 to 8 business day urgent turnaround
- Free shipping worldwide
Frequently Asked Questions
Do you supply an insert to stop the bottle moving?
Yes. A die cut paperboard cradle holds the neck and base so nothing shifts. For multipacks we build divided inserts.
Will the carton survive if the bottle leaks a little?
Laminated stock copes better than uncoated with minor residue. For anything caustic we recommend an internal liner or a poly sleeve as well.
Can you print a spray bottle box for a chemical product?
We can, and we lay out the GHS panel to your supplied wording. We print the compliance copy, we do not write it.
Trigger spray or fine mist, does it change the box?
It does. Trigger heads are wider and taller so the carton needs extra clearance at the top and across the shoulder.
What is the price for a spray bottle box?
Rough estimate is $0.35 to $0.95 per unit for folding cartons, $0.90 to $2.20 for corrugated mailers and $1.60 to $3.80 for multipack shippers at moderate quantities. Window patches and foil add to it. Shipping is included in our price. This is estimate only, so ask our team for a exact quote.
Can you do a multipack of four?
Easily. Divided corrugated shipper, each bottle sits in its own cell so nothing knocks together in transit.
Which finish handles a damp cupboard best?
Gloss or matte film both help. Uncoated kraft absorbs moisture and starts looking tired quickly in a laundry or bathroom.
