Custom 4 Oz Bottle Boxes & 4 Oz Bottle Packaging
Four ounces is probably the busiest bottle size we deal with. It sits right in the middle of skincare, hot sauce, hair oil, tincture, candle and craft beverage, which means a 4 oz bottle box has to work across wildly different shelves. We print a lot of this at ZEE Packaging and the same handful of things decide whether it comes out well.
The Cap Is What Trips People Up
Almost every sizing mistake we see in 4 oz bottle packaging comes from measuring the bottle and forgetting what sits on top.
- Measure to the top of the cap, not the neck
- Pump and dropper add real height, sometimes an inch or more
- Sprayers add height and often width at the trigger
- Flip top and disc caps are the shallowest
- Add 1mm to 2mm clearance so the flap closes flat
Send us the bottle with cap fitted, or just mail one over. We size the 4 oz bottle box here and there is no guessing.
Common Dimensions
Bottle shapes vary a lot at this volume, so these are the ranges we run most:
- 2" x 2" x 5" for a standard cylindrical 4 oz bottle box
- 2.25" x 2.25" x 6" for pump and dropper bottles
- 2.5" x 1.5" x 5.5" for boston round with a taller cap
- 1.75" x 1.75" x 6.5" for slim tincture 4 oz bottle packaging
- 3" x 3" x 5" for square glass and thicker walls
- 6" x 4" x 5" for a two or three bottle set
Glass Or Plastic Changes The Board
- Glass at 4 oz has real weight, we recommend 18pt to 24pt cardstock minimum
- PET and HDPE plastic can sit happily on 14pt to 16pt
- Corrugated E flute if the 4 oz bottle box ships alone with no outer carton
- Rigid greyboard 36pt for premium and gift 4 oz bottle packaging
- SBS C1S for clean printed retail cartons
- Kraft board for organic, apothecary and botanical ranges
Thin board looks fine in the proof and then a glass bottle bows the base panel within days. It is the single most common fix we make for clients.
Carton Styles
- Reverse tuck end, cheapest and fastest 4 oz bottle box
- Straight tuck end for a cleaner front face
- Seal end when you want tamper evidence
- Auto lock bottom for heavier glass, it saves packing time
- Window carton with PET patch so the liquid color shows
- Rigid or drawer style for gift 4 oz bottle packaging
Print And Finish
- Offset for volume, digital for short run 4 oz bottle packaging
- CMYK plus Pantone spot for exact brand color
- Soft touch lamination, very popular in skincare
- Matte film with spot UV over the logo
- Foil stamping in gold, copper and silver
- Emboss or deboss on kraft, understated and cheap
Panel Copy To Plan For
- Net contents in fl oz and ml
- Ingredient list where required
- Batch and expiry space, leave it blank for inline coding
- Business name and address
- Barcode with clear quiet zone
- Warning or usage directions
Our prepress team checks every panel against the dieline so nothing gets trimmed at the fold.
Greener Choices
- Recycled kraft 4 oz bottle box with no film
- FSC certified board, certificate on request
- Soy based ink through the run
- Paperboard insert instead of foam
- Right sized 4 oz bottle packaging so you ship less air
How We Work
- 100 unit minimum on any 4 oz bottle box design
- Free 3D mockup and flat proof
- Free dieline from our own designer
- 5 to 8 business day urgent turnaround
- Free shipping worldwide
Frequently Asked Questions
How much does a box for a 4 oz bottle cost?
Rough estimate is $0.28 to $0.85 per unit for folding cartons, $0.90 to $2.20 for mailers and $2.00 to $5.00 for rigid at moderate quantity. Window patches and foil add to it. Shipping is included in our price. This is estimate only, so ask our team for a exact quote.
Which board for a 4 oz glass bottle?
18pt is our floor, 20pt is safer if the glass is thick walled. Below that the base panel starts bowing under weight.
Do we need an insert?
For a single bottle usually not, correct sizing does the job. For multipacks or glass we build a paperboard divider so nothing knocks together.
Can you do a window on a small carton?
Yes, with clear PET patch. On narrow panels we keep the window slim so the carton stays rigid.
How do you leave room for batch coding?
We mark a clear blank zone on the dieline, normally on the base or a side flap, so your coder has somewhere to print.
Do you supply bottle labels too?
We do. Lots of clients order cartons and labels in one job so the colors match across both.
Straight tuck or reverse tuck?
Reverse tuck is cheaper. Straight tuck gives a cleaner front face and we suggest it for anything shelf facing.
