Custom 5 Oz Bottle Boxes & 5 Oz Bottle Packaging
Five ounces is a funny size to pack. It is too big to feel like a sample and too small to carry a lot of design, so every panel has to earn its place. We print a fair bit of 5 oz bottle packaging at ZEE Packaging across skincare, sauce, tincture and beverage, and the same handful of questions come up every time.
Know Your Bottle Before Anything Else
A 5 oz bottle box lives or dies on fit. Two bottles at the same fill volume can differ by half an inch in height depending on the closure.
- Boston round with dropper, tall and narrow
- Cosmo round with pump, adds real height at the top
- Cylinder glass with disc cap, the most compact option
- Square or oval glass, wider footprint and a shallower box
- PET plastic squeeze, lighter so the board can be thinner
Measure the bottle with the cap on, include pump reach if there is one, and send us the numbers. We build the dieline from that, not from the fill volume.
Common Dimensions We Run
Every 5 oz bottle box is made to your product, but these come up over and over:
- 2" x 2" x 5" for a slim boston round 5 oz bottle box
- 2.25" x 2.25" x 5.5" for cosmo round with pump
- 2.5" x 2.5" x 5" for a wider cylinder
- 3" x 2" x 5.5" for square and oval glass
- 6" x 4" x 6" for a two bottle 5 oz bottle packaging set
- 8" x 6" x 6" for a four bottle shipper
Board Weight Matters With Glass
This is the mistake we correct most often in 5 oz bottle packaging. Glass has weight and thin board gives way at the base.
- 16pt is the absolute floor and only for PET bottles
- 18pt to 20pt is our normal recommendation for glass
- 24pt when the 5 oz bottle box has heavy ink coverage or a window
- SBS C1S for smooth printed retail 5 oz bottle boxes
- Kraft board for organic, herbal and apothecary ranges
- Corrugated E flute when the box ships on its own
- Rigid greyboard 36pt for gift and luxury 5 oz bottle packaging
Styles That Suit A Bottle
- Reverse tuck end, cheapest and quickest
- Straight tuck end, cleaner front face for shelf
- Seal end carton with glued flap for tamper evidence
- Auto lock bottom, worth it once glass weight is involved
- Window carton so the liquid color shows through
- Sleeve over a tray for premium 5 oz bottle packaging
Finishing Choices
- Matte or gloss lamination
- Soft touch, very popular in skincare 5 oz bottle box work
- Spot UV over the logo or an illustration
- Foil stamping in gold, silver and copper
- Emboss or deboss on kraft, subtle and cheap
- Window patch with clear PET film
The Copy That Has To Fit
Small panels fill up fast, so plan this early.
- Net contents in fl oz and ml
- Ingredient list, INCI order for cosmetics
- Batch and expiry space, leave it blank for inkjet coding
- Business name, address and country of origin
- Warning or usage statement
- Barcode with proper quiet zone
Our prepress team checks all of it on the dieline so nothing gets trimmed at the edge.
Greener Choices
- Recycled kraft 5 oz bottle box with no film
- FSC certified board, certificate on request
- Soy based ink
- Paperboard insert instead of foam for multipacks
- Right sized 5 oz bottle packaging so you ship less air
How We Work
- 100 unit minimum on any 5 oz bottle box design
- Free 3D mockup and flat proof
- Free dieline from our own designer
- 5 to 8 business day urgent turnaround
- Free shipping worldwide
Frequently Asked Questions
Which board for a 5 oz glass bottle?
18pt minimum and 20pt if the glass is thick walled. Below that the base panel starts bowing once the carton sits on shelf a while.
How much is a box for a 5 oz bottle?
Rough estimate is $0.30 to $0.85 per unit for folding carton, $0.90 to $2.20 for mailer and $2.00 to $5.00 for rigid at moderate quantity. Window patch and foil add to it. Shipping is included in our price. This is an estimate only, so ask our team for an exact quote.
Do I need an insert?
For a single bottle, usually no if the fit is right. For multipacks we always build a divider so the glass doesn't knock together.
Tuck end or auto lock bottom?
Auto lock if you are hand packing at volume, it saves real time and holds weight better. Tuck end is cheaper for lighter PET bottles.
Can you add a window?
Yes, with clear PET patch or a plain die cut if you want it fully recyclable. Works nicely when the liquid has a good color.
Will the carton survive a humid bathroom?
Laminated stock handles humidity much better than uncoated. Matte film is what we normally suggest for skincare.
Do you print the label as well?
We do. Lots of clients order cartons and bottle labels in one job so the colors match across both.
